Advantages
Saves high labour costs.
Increases plant productivity and capacity.
Removes any kind of dirt, even below 20 micron.
Extreme cleaning homogeniety.
Shorter cleaning cycles than other systems.
Easy automation of in/out-let parts flow.
Customized design for any kind of material or form.
Reduces consumption of detergents and other chemicals .
Minimizes non-conformity of series for quality reasons.
Fully automated dosing of chemicals and maximum yearly average working times.
Product Description
| Model: Skymen™ | JTS-1012 | JTS-1018 | JTS-1024 | JTS-1030 | JTS-1036 | JTS-1072 |
| TANK'S WORKING DIMENSION (mm) | L1 | 355 | 406 | 500 | 500 | 500 | 1110 |
| W1 | 305 | 305 | 355 | 406 | 460 | 600 |
| H1 | 355 | 460 | 500 | 500 | 550 | 600 |
| OVERALL DIMENSION (mm) | L2 | 535 | 586 | 680 | 710 | 710 | 1320 |
| W2 | 485 | 485 | 535 | 586 | 640 | 780 |
| H2 | 750 | 680 | 720 | 720 | 770 | 820 |
| TANK'S TOTAL CAPACITY | 38L | 56L | 88L | 101L | 126L | 369L |
| TANK'S MATERIAL | SUS304 / SUS316L |
| IN-TANK SURFACE FINISHING | Hard-Cr Plating Treatment ( 20+ microns ) |
| HOUSING'S MATERIAL | Stainless steel |
| ULTRASONIC FREQUENCY* | 28kHz / 40kHz |
| ULTRASONIC TRANSDUCER | 12 | 18 | 24 | 30 | 36 | 72 |
| ULTRASONIC OUTPUT POWER (MAX.) | 600W | 900W | 1200W | 1500W | 1800W | 3600W |
| ELECTRONIC GENERATOR | KG600 | KG900 | KG1200 | KG1500 | KG1800 | KG3600 |
| Build-in | Separate |
| HEATER'S (HOT PLATE) POWER | 1.5kW | 3kW | 4.5kW | 9KW |
Skymen Cleaning Equipment Shenzhen Co., Ltd., which engaged in ultrasonic cleaner field for more than 7 years. Our main products are ultrasonic cleaner with different capacity.
Our company is a famous ultrasonic manufacturer with R&D, production and sales. High quality product and after sales services is available from us.
Not only standard ultrasonic cleaner, any non-standard can be design by our engineer.
Suggestion and drawing is professional for you.
Welcome to visit our factory, provide your precious guidance and conduct business negotiation.
Notification:
Voltage with AC110V, signal phase, AC220V/380V three phase are no problem for us.
Please inform us when you make order.
FAQ:
Q:What are the advantages of Skymen ultrasonic cleaner over traditional cleaning methods?
A:1.minimize the use of manual labor
· 2.make cleaning and degreasing without the use of organic solvents
· 3.clean hard to reach areas of products and remove all types of dirt
·4.shorten the processes such as extraction, dispersion, purification, chemical reactions
·5. eliminates costly mechanical and chemical cleaning of heat exchangers
Q: What frequency is better for my parts?
A: Frequency is suggested based on pollutants in the objects.
28kHz frequency is stronger, better for car/motor/truck/vessel parts clean (remove oils, grease, pastes, etc. )
40kHz is better for pcb boards, electronic parts, etc.
Higher precision goods, higher frequency.
Q: Can ultrasonic cleaning damage parts?
A: Although the effect of thousands of implosions per second is very powerful, the cleaning process is safe. No damage to your daily objects.
Q: What cleaning solution should I use?
A:A large variety of different formulas designed for specific applications. Proper selection is crucial for acceptable cleaning activity and to prevent unwanted reactions with the workpiece.
Q: Is rinsing after cleaning cycles?
A: Rinsing is recommended to remove any chemical residue that could be harmful to the part. Details can be rinsed right in your ultrasonic cleaner or in a clean water bath or in a separate sink tap, distilled or deionized water.
Q:How about after sales services?
A: 1 Year warranty for Skymen ultrasonic cleaner.
If any technical problem during warranty time, replacement parts will be sent free of charge. And technical support is also available after 1 year.
